ABIS CIRCUITS CO., LTD
Created in 2006,as a long history China based PCB supplier, ABIS manufactures different kinds of printed circuit boards, including MCPCB,CEM-1,CEM-3,and FR4,FR-4 high Tg, Rogers, Teflon, Arlon ets special material.
ABIS has set up two PCB factories in China: one for MCPCB producing, quick turn and small volumn making, and another for mass production. Currently, ABIS modern plants occupy total 10000 s.q.m facility, with more than 1100 stable and experienced workers. Professionalism and continuous optimization of manufacturing processes have positioned ABIS as a reliable and favorite partner for global companies.
| Items | Single/Double-sidedBoard/MutilayerBoard/FPC(1-24Layer) |
| BaseMaterials | FR-4(HighTG150*-170^),FR1.Aluminum,CEM-3,BT,94V0 |
| Finishcopperthickness | Outer6OZ,nner40Z |
| Surfacefinish | ENIG,ImAg.ImSn,0SP,HASL,Platinggold |
| FinishedBoardSize | MaxDouble-sidedBoard | 640mmX1100mm |
| MaxMutilayerBoard | 640mmX1100mm |
| FinishedBoardHoleSize(PTHHole) | MinFinishedBoardHoleSize | 0.15mm |
| ConductorWidthandSpacing | MinConductorWidh | 0.01mm |
| MinConductorSpacing | 0.01mm |
| ThicknessofPlatingandCoatingLayer | PTHwallCopperThickness | >0.02mm |
| TinSolderThickness(HotAlrLeveling) | >0.02mm |
| Nickl/GoldThickness | Forcustomerspecialneed |
| NicklPlatingLayer | >2um |
| GoldPlatingLayer | >0.3um |
| BareBoardTest | SinglesideTest | MaxTestPoint | 20480 |
| MaxBoardTestSize | 400mmx300mm |
| DoubleSldeTest | MaxTestPoint | 40960(GeneralUse) |
| 4096(SpecialUse) |
| MaxBoardTestSize | 406mmx325mm |
| 320mmx400mm |
| MinTestpitchofSMT | 0.5mm |
| TestVoltage | 10-250V |
| MechanicalProcess | Chamfer | 20*,30*,45*,60* |
| AngleTolerance | |
| DeepnessTolerance | 士0.20mm |
| V.CutAngle | 20",30*,45* |
| BoardThickness | 0.1-3.2mm |
| ResiduesThickness | :0.025mm |
| CellParapositionPrecision | 士0.025mm |
| ToleranceofOut-shapeProcess | 土0.1mm |
| BoardWarp | MaxValue | 0.7% |
| Optical Plotting | MaxPlottingArea | 66mmX558.8mm |
Q/TLead Time
| Category | Quickest Lead Time | Normal Lead Time |
| Double sides | 24hrs | 120hrs |
| 4 layers | 48hrs | 172hrs |
| 6 layers | z2hrs | 192hrs |
| 8 layers | 96hrs | 212hrs 268hrs |
| 10 layers | 120hrs |
| 12 layers | 120hrs | 280hrs |
| 14 layers | 144hrs | 292hrs |
| 16-20 layers | Depends on the specific requirements |
| Above 20 layers | Depends on the specific requirements |
FAQ
Q1:Are you a factory or trade company?
A: Abis is a PCB/FPC/PCBA manufacturer/factory. We pecialize in PCB/PCBA Board for 11 years.
Q2:Is my PCB file safe if I send it to you for manufacturing?
A: We respect customer's design authority and will never manufacture PCB for someone else without your permission. NDA is acceptable.
Q3:What is your testing policy and how you control the quality?
A: For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture, this will be more faster. Due to there's many steps to PCB production, we usually do inspection after every step.
Q4: What's your shipping way ?
A: 1. We have our own forwarder to ship goods by DHL, UPS, FEDEX, TNT,EMS.
2. If you have your own forwarder, we can cooperate with them.
Q5: What is your certificate?
A: ISO9001:2008, ISO14001: 2004, UL, SGS report.
Q6: What files should we offer?
A: If only need PCB, please provide Gerber File and manufacturing specifications; If need PCBA,Please provide Gerber File, Manufacturing specification, BOM list and Pick & Place/XY file.
Q7: Can I get a sample?
A: Yes, It's reasonable to get a sample to test our quality at first.
Q8: Why choose us?
A: With ABIS, customers significantly and effectively reduce their global procurement costs. Behind each service provided by ABIS, is hidden a cost saving for customers.
. We have two shop together, one is for prototype, quick turn, small volume making. The other is for mass production also for HDI board, with highly skilled professional employees, for high quality products with competitive price and on-time delivery.
. We provide very professional sales, technical and logistic supports, on a world-wide basis.hours complaint feedback.
Please keep us informed for any interestes!
ABIS cares every your order even 1 pcs
