Turnkey PCB Assembly Applied Metering with LCD Display
Abis Circuits Co., Ltd is a professional PCB manufacturer in China, Shenzhen. With 14 years+ development, we could make the PCB from 1L to 20L, with monthly production capability of 60,000 square meters. Abis Circuits is providing high-quality bare PCB and PCB assembly service, including components sourcing, function test, conformal coating, and complete assembly for clients all over the world, Our main market is Europe, north USA, Australia, South America, and Asia.
Factory: Operation plant space: (I) 10000 Square meters (II) 60000 Square meters
Employees: (I) 300 Man Powers (II) 900 Man Powers
Eng. Technical: (I) 20 QA QC Engineers (II) 60 QA, QC Engineers
Our assembly technology Capabilities (RoHS Compliant) up to:
-0201 Chip Size
-12 mils Integrated Circuit (IC) Pitch
-Micro Ball Grid Array (BGA) – Pitch 16 mils
-Flip Chip (Controlled Collapse Chip Connection) – Pitch 5 mils
-Quad Flat Package (QFP) – Pitch 12 mils
-Nitrogen Reflow
-Wave soldering
-Selective conformal coating
Lead Time
| Category | Q/T Lead time | Standard Lead Time | Mass Production |
| |
| 2 Layers | 24hrs | 3-4 working days | 8-15 working days |
| |
| 4 Layers | 48hrs | 3-5 working days | 10-15 working days |
| |
| 6 Layers | 72hrs | 3-6 working days | 10-15 working days |
| |
| 8 Layers | 96hrs | 3-7 working days | 14-18 working days |
| |
| 10 Layers | 120hrs | 3-8 working days | 14-18 working days |
| |
| 12 Layers | 120hrs | 3-9 working days | 20-26 working days |
| |
| 14 Layers | 144hrs | 3-10 working days | 20-26 working days |
| |
| 16-20 Layers | Depends on the specific requirements |
| |
| 20+ Layers | Depends on the specific requirements |
Quality Control:
Multiple quality assuring procedures
* Visual Inspection
* Flying probe, fixture tool
* Impedance control
* Solder-ability detection
* Digital metallographic microscope
* AOI (Automated Optical Inspection
FAQ:
Q1: How can I get a quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber
Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide a sample?
Q3: Do you have PCB in stock?
. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality checking always.
Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan), and Shengyi (China).
Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engineer's question and working file be approved, production will start.
Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
